Light Yellow LCP 1.25mm Pitch Connector , Wire To Board Terminal Connector One Row

China Light Yellow LCP 1.25mm Pitch Connector , Wire To Board Terminal Connector One Row supplier
Light Yellow LCP 1.25mm Pitch Connector , Wire To Board Terminal Connector One Row supplier Light Yellow LCP 1.25mm Pitch Connector , Wire To Board Terminal Connector One Row supplier

Large Image :  Light Yellow LCP 1.25mm Pitch Connector , Wire To Board Terminal Connector One Row

Product Details:

Place of Origin: Dongguan, China(mainland)
Brand Name: HRT
Certification: ISO9001/ ISO14001/UL/RoHS/REACH
Model Number: A1257WVA-S-NP

Payment & Shipping Terms:

Minimum Order Quantity: 5000 pcs
Price: USD0.001 to 0.005 per pcs
Packaging Details: Tube(pipe) with outside paper carton
Delivery Time: 5 to 8 working days after payment checked
Payment Terms: TT, Western Union, PayPal, L/C
Supply Ability: 28 million pcs per month
Detailed Product Description
Color: Light Yellow Pitch: 1.25mm
Wafer Materials: LCP, UL94V-0 Wire Range: AWG32# To 28#
Packaging Type: Bags Suitable Housing: A1257HA Single Row Series
High Light:

Wafer Connector 2.0mm

,

Housing Connector

,

LCP 1.25mm Pitch Connector



Light Yellow LCP 1.25mm Pitch Connector , Wire To Board Terminal Connector One Row



1, Detailed specification of product:



Detailed information


















Basic information

Type Wafer connector
Gender Female
Circuits 2 to 20 positions
Insulation O.D. 0.80mm(max)
Mating lock With
Pin materials Brass or gold-flash
Solder tabs Brass/Gold flash
Wafer material LCP,UL94V-0
Cap Nylon6T,UL94V-0
Matched housing A1257HB single row series
Mounting type Right angle
Application Signal, wire to board
Terminal materials Phosphor bronze
Finish terminal Tin-plated or gold-flash type
Terminal Package 15K pcs/reel
Terminal processing method E-stamping before tin-plated






Electrical properties

Current Rating 1A AC, DC
Voltage Rating 50V AC, DC
Contact Resistance 30mΩ Max
Insulation Resistance 100mΩ Min
Withstanding Voltage 500V AC/minute






Mechanical properties

Temperature range -25℃ to 85 ℃
Terminal Insertion Force 0.50kgf (Max.)
Terminal/Housing Retention Force 0.50kgf (Min.)
Pin Retention Force 0.50kgf (Min.)

Other information please kindly check the following picture.





2, Introduction for this series products

Please kindly notice these series product, you can buy it as a set, then we will offer you reasonable price.

                                                              A1257 series product
                  Terminal A1002-T

                    Housing Dual housing A1257HA-2XNP
Single housing A1257HB-NP

                     Wafer Single row type A1257WRB-S-NP
Dual rows type A1257WVA-SF-2XNP





3, Corresponding engineering drawing & test report

Below file is our engineering drawing and testing report for further information. It's sure that it will be a

good reference for you to know this series parts clearly.



                                                                Drawing of dimension

Light Yellow LCP 1.25mm Pitch Connector , Wire To Board Terminal Connector One Row

Light Yellow LCP 1.25mm Pitch Connector , Wire To Board Terminal Connector One Row

Light Yellow LCP 1.25mm Pitch Connector , Wire To Board Terminal Connector One Row

6. Environmental Performance And Others



Test Description Procedure Requirement
6-1 Temperature Rise Carrying rated current load.(Based upon UL 498) 30℃(Max.)
6-2 Heat Resistance 85±2℃,96 hours (Based upon JIS C0021/MIL-STD-202 Method 108A Cond. A)

Appearance No Damage.

Contact Resistance 40mΩ (Max.)

6-3 Cold Resistance -25±3℃,96 hours (Based upon JIS C0020)
6-4 Humidity

Temperature: 40±2℃

Relative Humidity : 90~95%

Duration: 96 hours

(Based upon JIS C0022/MIL-STD-202 Method 103B Cond. B)

Appearance No Damage.

Contact Resistance 40mΩ (Max.)

Insulation Resistance 10MΩ (Min.)

Dielectric Withstanding Voltage Must meet 4-3

6-5 Temperature Cycling

5 cycles of:

a) -55℃ 30 minutes

b) +85℃ 30 minutes

(Based upon JIS C0025)

Appearance No Damage.

Contact Resistance 40mΩ (Max.)

6-6 Salt Spray Tin-plated 12 hours / Gold- plated 24 hours exposure to a salt spray from the 5±1% solution at 35±2℃. (Based upon JIS C0023/MIL-STD-202 Method 101C Cond. B)
6-7 SO2 Gas

24 hours exposure to 50±5ppm.

SO2 gas at 40±2℃.

6-8 NH3 Gas 40 minutes exposure to NH3 gas evaporating from 28% Ammonia solution.



7. Actuator Insertion/Withdrawal Force

[Unit : kgf]

Circuits At Initial
Insertion (Max.) Withdrawal (Min.)
Single 0.20 0.03
2X05 2.20 0.25
2X08 2.70 0.35
2X10 3.20 0.50
2X15 4.20 0.75
2X18 4.70 0.88
2X20 5.20 1.00
2X21 5.30 1.03
2X25 7.20 1.25
2X30 8.20 1.50


























4, FAQ

Q:Do you allow multiple design per setup?
A:Yes.We accept OEM service and allow multiple design per setup.

Q:How long does shipping take?
A:It depends on the destination location and quantity. In most developed world, delivery by Fed x/UPS/DHL is normally 2-3 days(excluding weekends).

Q: How is the goods packaged ?
A: Usually in vacuum packages and carton box.
