1.25mm Pitch Board-in Housing 5 Circuits Crimp connectors Wire to Board Connector

1.25mm Pitch Board-in Housing 5 Circuits Crimp connectors Wire to Board Connector

    • 1.25mm Pitch Board-in Housing 5 Circuits Crimp connectors Wire to Board Connector
    • 1.25mm Pitch Board-in Housing 5 Circuits Crimp connectors Wire to Board Connector
    • 1.25mm Pitch Board-in Housing 5 Circuits Crimp connectors Wire to Board Connector
  • 1.25mm Pitch Board-in Housing 5 Circuits Crimp connectors Wire to Board Connector

    Product Details:

    Place of Origin: Dongguan, China(mainland)
    Brand Name: HRT
    Certification: ISO9001/ ISO14001/UL/RoHS/REACH
    Model Number: B1259HV-NP

    Payment & Shipping Terms:

    Minimum Order Quantity: 5000 pcs
    Price: negotiated
    Packaging Details: Bag with outside carton
    Delivery Time: 5 to 8 working days after payment checked
    Payment Terms: TT, Western Union, PayPal, L/C
    Supply Ability: 28 million pcs per month
    Contact Now
    Detailed Product Description
    Category: Crimp Housings Mated Terminal Material: Phosphor Bronze
    Circuits: 2 To 15pins Panel Mount: No
    Flammability: UL94V-0 Wire Insulation Diameter: 1.00mm Max.
    High Light:

    Wire To Board Connector

    ,

    PCB To PCB Connector



    1, The detailed product datasheet

    Following datasheet will be helpful for you to buy right parts from us, and the part will have a

    good perfromance in your device.


    General Information
    Category Crimp Housings
    Series:B1259HV-NP
    Application: Signal

    Physical Information
    Circuits (maximum):15
    Color - Resin Natural
    Gender: Male
    Glow-Wire: Compliant No
    Material: - Resin Polyester
    Net Weight: 39.0001.25mm Pitch Board-in Housing 5 Circuits Crimp connectors Wire to Board Connector
    Number of Rows: 1
    Packaging Type: Bag
    Panel Mount: No
    Pitch: - Mating Interface 1.25mm
    Stackable: No
    Temperature Range - Operating: -40°C to +85°C


    2, Related drawing and report

    Folllowing pictures are out testing report and exact engineering drawing for your information, please kindly check it, wish it can help you to get what you really need.

    1.25mm Pitch Board-in Housing 5 Circuits Crimp connectors Wire to Board Connector


    3, Application fied of these product

    This product is ideal for most of household appliance, computer, communication device. Our parts are trusted by renowned company like TPV, Emerson, Amphenol Corporation, Skyworth, LuXshare, BYD etc. And the all products are certificated by REACH, UL, RoHS. We know our resposibility to protect environment, some parts are complied with halogen free standard. Please see our main customer picture

    as below.





    4, Why choose us


    1). We are in Donguan,the hometown of electronics parts in China. We can provide you the most competitive products.

    2). We have sampling hundreds of products type for our custom in the past 12 years.

    3).There is a a pool of experienced, sophisticated work of the top technical talent, and use of advanced automated production equipment, full assurance of the quality of the products.

    4). Your sample demand can be finished in a short time, it order to save your time and make more money.
