| Place of Origin: | Dongguan, China(mainland) |
| Brand Name: | HRT |
| Certification: | ISO9001/ ISO14001/UL/RoHS/REACH |
| Model Number: | C3030HMA-2XNP |
| Minimum Order Quantity: | 5000 pcs |
|---|---|
| Price: | Negotiated |
| Packaging Details: | Bag with outside carton |
| Delivery Time: | 5 to 8 working days after payment checked |
| Payment Terms: | TT, Western Union, PayPal, L/C |
| Supply Ability: | 20 million pcs per month |
| Category: | Power Cable Connector | Suitable Terminals: | C3030F Series |
|---|---|---|---|
| Flammability: | UL94V-0/2 | Material: | PA66 |
| Positions: | 2 To 24 Circuits | Gender: | Female |
| Colour: | Black | ||
| High Light: | Wire To Wire Connector,Power Splitter Cable |
||
1, Detailed information of product feature
| Basic dimension information | |||
| Application | Power, wire-to-wire,wire-to-board | ||
| Pitch | 3.00mm | ||
| Color | black | ||
| Row | Dual/Double | ||
| Bump | Without | ||
| Wire range | AWG22# to 24# | ||
| Wire insulation diameter | 1.85mm Max | ||
| Terminal materials | Phosphor bronze material, tin-plated or gold-flash finish | ||
| Electrical properties | |||
| Current Rating | 3.0A AC, DC | ||
| Voltage Rating | 250V AC, DC | ||
| Contact Resistance | 10mΩ Max | ||
| Insulation Resistance | 500MΩ min | ||
| Withstanding Voltage | 1500V AC/minute | ||
| Mechanical properties | |||
| Temperature range | -25℃ to 85 ℃ | ||
| Terminal Insertion Force | 1.50kgf (Max.) | ||
| Terminal/Housing Retention Force | 2.50kgf (Min.) | ||
| Pin Retention Force | 1.50kgf (Min.) | ||
| Latch Yield Strength | 7.0kgf (Min.) | ||
| Other information please kindly check the following picture. | |||
2, Related drawing and report
Folllowing pictures are out testing report and exact engineerin g drawing for your information, please kindly check it, wish it can help you to get what you really need.
3, Introduction for this series products
Please kindly notice that the C3030 series product, you can buy it as a set, then we will offer you reasonable price.
| C3030 series product | ||
| Terminal | C3030F-T-A and C3030M-T | |
| Connector | Male housing | C3030HF-NP & C3030HF-2XNP &C3030HFA-2XNP |
| Female housing | C3030HM-NP & C3030HMA-NP &C3030HM-2XNP & C3030HMA-2XNP | |
|
Wafer |
Vertical type | C3030WV-F-NP &C3030WV-F-2XNP |
| Right angle type | C3030WR-F-XP & C3030WR-F-2XNP | |
